Cob Led Display Screen Cabinet
Product Description
A COB LED display Screen Cabinet is a high-quality cabinet structure specially customized for COB LED displays. Here are its main features:
Functions and Performance:
Protection: It provides excellent protection for the COB LED display screen. It can protect the screen from external impacts, dust, moisture, and other factors that may damage the display, ensuring the stability and durability of the display screen. This makes it suitable for use in a wide range of environments, including both indoor and outdoor settings with relatively harsh conditions.
Display Effect: The cabinet is designed to enhance the display effect of the COB LED Screen. It can ensure the flatness and consistency of the screen, making the displayed images and videos more vivid, clear, and colorful. With the characteristics of high brightness, high contrast, and wide viewing angle of the COB LED display, the overall visual effect is very outstanding.
Installation Methods: The installation method of the COB LED display screen cabinet is usually wall-mounted or ceiling-mounted, which can be flexibly selected according to different application scenarios and installation requirements.
Functions and Performance:
Protection: It provides excellent protection for the COB LED display screen. It can protect the screen from external impacts, dust, moisture, and other factors that may damage the display, ensuring the stability and durability of the display screen. This makes it suitable for use in a wide range of environments, including both indoor and outdoor settings with relatively harsh conditions.
Display Effect: The cabinet is designed to enhance the display effect of the COB LED Screen. It can ensure the flatness and consistency of the screen, making the displayed images and videos more vivid, clear, and colorful. With the characteristics of high brightness, high contrast, and wide viewing angle of the COB LED display, the overall visual effect is very outstanding.
Installation Methods: The installation method of the COB LED display screen cabinet is usually wall-mounted or ceiling-mounted, which can be flexibly selected according to different application scenarios and installation requirements.
| Model | U121 | U151 | U181 | U251 |
| Pixel pitch (mm) | 1.25 | 1.56 | 1.875 | 2.5 |
| Configurations | SMD1010 | SMD1212 | SMD1515 | SMD1515 |
| Module size(mm) | 300*168.75mm | 150*337.5mm | ||
| Scanning mode | 1/45 | 1/54 | 1/45 | 1/30 |
| Cabinet size(mm) | 600x337.5x40 | |||
| Cabinet material | Die casting aluminum | |||
| Greyscale | 14bit | |||
| Refresh rate | 3840Hz | |||
| Brightness | 450nit | 450nit | 600nit | 900nit |
| Viewing angle | 170°（H）/170°（V） | |||
| Max. Power consumption (W/㎡) | 600 | 600 | 600 | 550 |
| Ave. Power consumption (W/㎡) | 200 | 175 | 220 | 220 |
| Installation/maintenance type | Stack ,wall mount / totally front | |||
Our company is committed to providing a diverse range of products and services, Mini LED Screen,LCD Video Wall,Indoor Digital Signage， Welcome to inquire!
