LCD Indoor videowall monitor advertising display

LCD Indoor videowall monitor advertising display
LCD panel: This is the core component, multiple LCD panels are connected together through special interfaces and splicing controllers to form a large display screen. LCD panels have the characteristics of high resolution, high contrast, and rich colors, which can present clear and realistic images.
Splicing controller: responsible for distributing the input video signal to each LCD panel, ensuring that the image can be displayed correctly on the spliced screen. The splicing controller can also process and adjust images, such as brightness, contrast, color, etc., to achieve the best display effect.
Frame structure: used to connect and fix LCD panels, the width of the frame directly affects the overall effect of the spliced screen. Narrow border design can reduce splicing gaps, improve the overall integrity and aesthetics of the screen.
Power system: Provide stable power supply for LCD splicing screens to ensure their normal operation.



oduct   Parameters	Panel	49 inch LG LTI460HN14
	Resolution	1920*1080
	Aspect ratio	16:9
	Response time	5ms
	Brightness	500cd/m2
	Contrast ratio	3000:1
	Color	16.7M
	Display area	1073.8x604.0mm
	Machine size	1077.6x607.8x110.9mm
	Bezel	3.9mm
	Visual angle	178
	Interface	AV/VGA/DVI/HDMI
	Input power	AC 100-240v,50-60HZ
	Product color	Black
Optional   Accessories(charges)	wall mount rack	normal/curve/Containing edges(200mm)
	Front maintenance bracket	136mm
	Floor stand	horizontal bar/parallel bars/curve
	HDMI spliter	8/16 interface
	HDMI HD cable	3m length
	converter	USB transform to RS232(COM)
Accessories(free)	net cable	RJ45,2m length
	Control software	DID split control software
