Mini Micro LED Video Wall Display
Product Description
The Mini Micro LED Video Wall Display represents a cutting-edge advancement in display technology.
Ultra-High Resolution: The mini Micro LED video wall offers an extremely high pixel density, resulting in incredibly sharp and detailed images. Whether it's displaying fine text, intricate graphics, or high-definition videos, the resolution is superb, providing a visually immersive experience.
Vivid Color Reproduction: With advanced color technology, these displays can reproduce a wide gamut of colors with exceptional accuracy and saturation. The result is vivid and lifelike images that truly pop, making them ideal for applications where color fidelity is crucial, such as advertising, entertainment, and art installations.
Micro LED Technology: Micro LEDs are tiny light-emitting diodes that offer several advantages over traditional display technologies. They are highly energy-efficient, have a long lifespan, and can be made extremely small, allowing for the creation of miniaturized displays with high resolution.
Ultra-High Resolution: The mini Micro LED video wall offers an extremely high pixel density, resulting in incredibly sharp and detailed images. Whether it's displaying fine text, intricate graphics, or high-definition videos, the resolution is superb, providing a visually immersive experience.
Vivid Color Reproduction: With advanced color technology, these displays can reproduce a wide gamut of colors with exceptional accuracy and saturation. The result is vivid and lifelike images that truly pop, making them ideal for applications where color fidelity is crucial, such as advertising, entertainment, and art installations.
Micro LED Technology: Micro LEDs are tiny light-emitting diodes that offer several advantages over traditional display technologies. They are highly energy-efficient, have a long lifespan, and can be made extremely small, allowing for the creation of miniaturized displays with high resolution.
| Technical Parameter | ||||
| Item | Pitch 1.25 | Pitch 1.86 | Pitch 2 | Pitch2.5 |
| Pixel pitch | 1.25MM | 1.86MM | 2MM | 2.5MM |
| Module size | 320x160MM | 320x160MM | 320x160MM | 320x160MM |
| Module resolution | 256x128 | 172x86 | 160x80 | 128x64 |
| Physical Density | 640000 dots/sqm | 288906 dots/sqm | 250000 dots/sqm | 160000 dots/sqm |
| LED type | SMD1010 | SMD1515 | SMD1515 | SMD2020 |
| Cabinet sie | 640x480MM | 640x480MM | 640x480MM | 640x480MM |
| Cabinet resolution | 512x384 | 344X258 | 320x240 | 256x192 |
| Cabinet weight | 8KG | 8KG | 8KG | 8KG |
| cabinet material | Die-casting aluminum | Die-casting aluminum | Die-casting aluminum | Die-casting aluminum |
| Maintenance way | Front access | Front access | Front access | Front access |
| Best viewing distance | >1.5M | >2M | >2M | >2.5M |
| Best viewing angle | H:160。;V:120。 | H:160。;V:120。 | H:160。;V:120。 | H:160。;V:120。 |
| Driving method(constant current) | 1/64 | 1/43 | 1/40 scan | 1/32 scan |
| Refresh rate | 1920-3840Hz | 1920-3840Hz | 1920-3840Hz | 1920-3840Hz |
| Brightness | >800 nits | >800 nits | >800 nits | >800 nits |
| Grey Level | 12-16 bit | 12-16 bit | 12-16 bit | 12-16 bit |
| Life time | >1000,000 hours | >1000,000 hours | >1000,000 hours | >1000,000 hours |
