Outdoor waterproof full color double sided led display

An outdoor waterproof full color double sided LED display is a type of LED display screen designed for outdoor use with several notable features and characteristics:

This is a crucial feature as it is exposed to various outdoor weather conditions such as rain, snow, and humidity. The display is constructed with high-quality waterproof materials and sealing technology to ensure that water cannot infiltrate the internal components of the screen. For example, the edges and joints of the screen are tightly sealed to prevent water from entering, and the electronic components are coated with waterproof coatings to enhance their resistance to moisture.

The double sided structure allows the display to be visible from two different directions, greatly increasing the visibility and coverage area. This is particularly useful in places with high traffic flow or where information needs to be conveyed to multiple directions, such as street intersections, shopping malls, and transportation hubs. For instance, in a busy city square, a double sided LED display can simultaneously display advertisements to people on both sides of the square, effectively improving the advertising effect and information dissemination efficiency.

ITEM	UNIT	ABX960A-P3	ABX960A-P4	ABX960A-P5	ABX960A-P6.667	ABX960A-P8	ABX960A-P10
Pixel Pitch	mm	3.076	4	5	6.667	8	10
Pixel Matrix Per	Pixel/sqm	105625	62500	40000	22500	15625	10000
Module Pixel structure	N/A	SMD1921	SMD1921	SMD1921	SMD3535	SMD3535	SMD3535
Brightness	nits	4500-5500Nits	4500-5500Nits	4500-5500Nits	5000-6000Nits	4500-6000Nits	4500-7200Nits
Scan	N/A	1/13	1/13	1/10	1/6	1/5	1/4,1/2
Cabinet Resolution	Pixel	240×240	192×192	160×160	144*144	120*120	96*96
Power Con. (Max / Avg)	W/sqm	600/180	600/180	600/180	600/180	600/180	600/180
Module Dimension	mm	320x160	320x160	192x192	320x160	320x160	320x160
Cabinet Dimension	mm	960x960x138	960x960x138	960x960x138	960x960x138	960x960x138	960x960x138
Cabinet Weight	kg	33kg	33kg	33kg	33kg	33kg	33kg
Service Access	N/A	Rear	Rear	Rear	Rear	Rear	Rear
View angle	℃	160°/ 140°	160°/ 140°	160°/ 140°	160°/ 140°	160°/ 140°	160°/ 140°
Refresh Rate	Hz	1920/3840/7680	1920/3840/7680	1920/3840/7680	1920/3840/7680	1920/3840/7680	1920/3840/7680
Grey Scale (bit)	bit	16	16	16	16	16	16
IP Rate	IP	IP65	IP65	IP65	IP65	IP65	IP65
Life span	hrs	100000 hrs	100000 hrs	100000 hrs	100000 hrs	100000 hrs	100000 hrs
Working Temperature	℃	-30-60 ℃
Storage Temperature	℃	-30-60 ℃
Power Supply	V	AC100-240V(50-60Hz)
Color temperature	N/A	3000-10000 K(adjustable)
