Outdoor LED Display Screen panel billboard

Outdoor LED display screen panel billboard is an electronic display device used for outdoor advertising, information dissemination, etc. It has the following characteristics and advantages:
Outdoor environments are usually well lit, even with strong sunlight. Therefore, outdoor LED display panel billboards have the characteristic of high brightness, with a general brightness of 2500cd/m ² or above, which can ensure that the displayed content is still clear and visible under various outdoor lighting conditions, attracting the attention of pedestrians and vehicles.
Waterproof, dustproof, and weather resistant: Long term exposure to outdoor environments requires resistance to various weather conditions such as rain, dust, high and low temperatures. Therefore, outdoor LED display panel billboards are designed and manufactured using waterproof, dustproof, and corrosion-resistant materials and processes, which have good protective performance and can ensure stable operation in harsh outdoor environments.
Adopting advanced LED lighting technology, it has lower energy consumption compared to traditional advertising lighting equipment. At the same time, some outdoor LED display panel billboards also have intelligent energy-saving functions, which can automatically adjust brightness according to ambient light and usage time, further reducing energy consumption.

Pixel Pitch	2.6mm	2.976mm	3.91mm	4.81mm
Led Module Size	250 x 250mm	250 x 250mm	250 x 250mm	250x250mm
Led Panel Size	500 x 500mm	500 x 500mm	500 x 500mm / 500x1000mm	500x500mm
Led Panel Weight	6.5KG	6.5KG	6.5KG/13KG	6.5KG
Refresh Rate	3840Hz	3840Hz	3840Hz	3840Hz
Drive Method	1/32 Scan	1/28 Scan	1/16 Scan	1/16 Scan
Brightness	1000nits	1000nits	1200nits	1200nits
Power Supply	Chuanglian/ G-energy/ MeanWell	Chuanglian/ G-energy/ MeanWell	Chuanglian/ G-energy/ MeanWell	Chuanglian/ G-energy/ MeanWell
Receiving Card	Novastar / Linsn / Colorlight / Huidu	Novastar / Linsn / Colorlight / Huidu	Novastar / Linsn / Colorlight / Huidu	Novastar / Linsn / Colorlight / Huidu
Max Power Consumption	200W/pcs	200W/pcs	200W/pcs	200W/pcs
Working Temperature	-20℃~+50℃	-20℃~+50℃	-20℃~+50℃	-20℃~+50℃
Best Viewing Distance	2-25m	2.5-30m	3-40m	3-8m
Best Viewing Angle	H: 140°; V:140°	H: 140°; V:140°	H: 140°; V:140°	H: 140°; V:140°
Life Span	100,000 hours	100,000 hours	100,000 hours	100,000 hours
Working System	Windows	Windows	Windows	Windows
