Outdoor Waterproof Signage Board Led Screen Display
Product Description
The outdoor waterproof signage board LED Screen display is a highly functional and durable advertising and communication tool. Here are its key features and benefits:
The most prominent feature of this LED screen display is its waterproof design. It is constructed with materials and sealing techniques that can effectively prevent water from infiltrating the internal components of the screen. This makes it suitable for outdoor use in all weather conditions, including rain, snow, and high humidity.
For example, the edges and joints of the screen are tightly sealed with waterproof gaskets or adhesive. The electronic components are also protected by waterproof coatings or enclosures. This ensures that the screen can operate reliably even in the harshest outdoor environments.
Outdoor environments are often exposed to strong sunlight and various lighting conditions. To ensure clear visibility, the outdoor waterproof signage board LED screen display is designed with high brightness. The LEDs used in these screens are capable of emitting intense light, making the displayed content easily visible even in direct sunlight.
The most prominent feature of this LED screen display is its waterproof design. It is constructed with materials and sealing techniques that can effectively prevent water from infiltrating the internal components of the screen. This makes it suitable for outdoor use in all weather conditions, including rain, snow, and high humidity.
For example, the edges and joints of the screen are tightly sealed with waterproof gaskets or adhesive. The electronic components are also protected by waterproof coatings or enclosures. This ensures that the screen can operate reliably even in the harshest outdoor environments.
Outdoor environments are often exposed to strong sunlight and various lighting conditions. To ensure clear visibility, the outdoor waterproof signage board LED screen display is designed with high brightness. The LEDs used in these screens are capable of emitting intense light, making the displayed content easily visible even in direct sunlight.
Model | P4 | P5.33 | P6.67 | P8 | P10 |
Pixel Pitch(mm) | 4 | 5.33 | 6.67 | 8 | 10 |
Pixel Matrix Per Sq.m | 62500dots | 35200dots | 22500dots | 15625dots | 10000dots |
LEDs package | SMD1921 | SMD1921 | SMD2727 | SMD3535 | SMD3535 |
Brightness (cd/㎡) | ≥6000cd/㎡ | ≥6000cd/㎡ | ≥6000cd/㎡ | ≥6000cd/㎡ | ≥6000cd/㎡ |
Scan | 1/10 | 1/8 | 1/6 | 1/5 | 1/4 |
Module Dimension | 320*320mm | 320*320mm | 320*320mm | 320*320mm | 320*320mm |
Cabinet Dimension | 960*960*160mm | 960*960*160mm | 960*960*160mm | 960*960*160mm | 960*960*160mm |
Cabinet Resolution | 240*240dots | 180*180dots | 144*144dots | 120*120dots | 96*96dots |
Cabinet Material | Iron | Iron | Iron | Iron | Iron |
Cabinet Weight | 40KGs | 40KGs | 40KGs | 40KGs | 40KGs |
Max. Power Consumption | 800W | 800W | 800W | 800W | 800W |
Ave. Power Consumption | 200-300W | 200-300W | 200-300W | 200-300W | 200-300W |
Service Access | Front and Rear | Front and Rear | Front and Rear | Front and Rear | Front and Rear |
Refresh Rate (HZ) | 1920HZ/ 3840HZ | 1920HZ/ 3840HZ | 1920HZ/ 3840HZ | 1920HZ/ 3840HZ | 1920HZ/ 3840HZ |
Grey Scale (bit) | 16 | 16 | 16 | 16 | 16 |
Viewing Angle (H/V) | 160°/160° | 160°/160° | 160°/160° | 160°/160° | 160°/160° |
Best Viewing Distance | 4-40m | 5-53m | 6-67m | 8-80m | 10-100m |
IP Rate | IP65 | IP65 | IP65 | IP65 | IP65 |
Input Voltage (AC) | 110V-240V, 50/60HZ | 110V-240V, 50/60HZ | 110V-240V, 50/60HZ | 110V-240V, 50/60HZ | 110V-240V, 50/60HZ |

Our company is committed to providing a diverse range of products and services, Mini LED Screen,LCD Video Wall,Indoor Digital Signage,LCD Interactive Whiteboard,Welcome to inquire!
